Overview

• Utilizes Premium-grade Input And Output Transformers From Cinemag Usa
• Fully Discrete Design With A Robust 71db Of Gain
• Utilizes A Discrete 6-pin Socketed 1731-style Opamp, Which Can Be Swapped With Other Designs That Conform To The 6-pin, 2520 Footprint +/- 16vdc Standard For Varying Tone And Flavor
• 20db Pad
• Tone Button – Switches The Input Impedance From 150 To 600 Ohms And Changes The Tone Of Both The Mic And Hi-z Inputs
• Mic Level Balanced Input: Xlr
• 2 Megohm True Hi-z Input On The Front Panel Which Sends The Signal Through The Entire Circuit, Including Both Cinemag Transformers And The X731 Opamp – Great For Guitars, Bass, Keys, Keyboards And Any Instrument With A 1/4” Output Jack
• Balanced Outputs: Xlr And 1/4″/trs
• 48 Volt Phantom Power
• Led Meter Gain Indication
• Output Attenuation Control (Positioned After The Cinemag Output Transformer) Allows For Driving The Preamp And Transformers Into Saturation
• Switchable 115/230 Volt Iec Power Inlet
