Overview
• User Drum Kit: 128
• User Patterns: 128
• Step Sequencer
• 11 instrument parts and 1 exclusive part for trigger out
• 16 steps per 1 variation
• 8 (A – H) variations per 1 pattern
• 2 Fill-in patterns per 1 pattern
INST tone
• (Tone can be assigned to each 11 instrument parts freely.)
• BASS DRUM: 11 ACB tones
• SNARE DRUM: 8 ACB tones
• TOM: 15 ACB tones
• RIM SHOT: 3 ACB tones
• HAND CLAP:5 ACB tones
• HI HAT: 8 ACB tones
• CYMBAL: 8 ACB tones
• PERCUSSION: 23 ACB tones
• PRESET SAMPLE: 300 tones or greater
• USER SAMPLE (imported form SD CARD for playback): Available format: WAV, AIFF
• Total time for all samples: Approximately 600 sec (at 44.1 kHz, mono)
* The maximum length of a single audio file that can be imported is approximately 180 seconds (at 44.1 kHz).
Effects
• INST FX: THRU, HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, COMPRESSOR, DRIVE, COMP+DRV, CRUSHER
• REVERB: AMBI, ROOM, HALL1, HALL2, PLATE, MOD
• DELAY: DLY, PAN, TAPE ECHO
• MASTER FX: HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, TRANSIENT2, COMPRESSOR, DRIVE, OVERDRIVE, DISTORTION, FUZZ, CRUSHER, PHASER, FLANGER, SBF, NOISE
• Other: SIDE CHAIN (for EXT IN), SCATTER (as one of AUTO FILL IN function)
Display
• 16 characters, 2 line (backlit LCD)
• 7 segments, 4 characters (LED)
External Storage
• SD Card (SDHC supported) for backup/restore function and import sample data
Connectors
• PHONES jack: Stereo 1/4-inch phone type
• MIX OUT (L/MONO, R) jacks: 1/4-inch TRS phone type
• ASSIGNABLE OUT/TRIGGER OUT (1 – 6) jacks: 1/4-inch phone type
• EXT IN (L/MONO, R) jacks: 1/4-inch phone type
• TRIGGER OUT jack: Miniature phone type
• MIDI (IN, OUT) connectors
• USB port: USB type B (Audio, MIDI)
• DC IN jack
Power Supply
• AC adaptor
Current Draw
• 2,000 mA
Accessories
• AC adaptor
• Owner’s manual
• Leaflet “USING THE UNIT SAFELY”
Size And Weight
• Width: 409 mm
• Depth: 263 mm
• Height: 58 mm
• Weight: 2.1 kg
