Voice Path

• 5-voice, 2x VCOs with saw, square/pulse, triangle, and noise
• Oscillator hard sync and X-Mod with through-zero FM
• Simultaneously selectable wave shapes plus sub oscillator
• Discrete SEM-lineage VCF delivers authentic Oberheim tone and presence
• Filter State knob morphs from low-pass to high-pass through notch, with selectable band-pass mode
• Poly and Mono LFOs with 5 wave shapes and tempo sync
• Meticulously modeled envelope responses based on OB-8
• Modulation matrix with 19 slots x 19 sources x 64 destinations in a flexible design where almost any mod route is possible, including audio rate sources and destinations.
• Enhanced unison allows variable voice stacking from 1-5 voices
• Polyphonic portamento
• Vintage knob recreates vintage synth characteristics by adding voice-to voice variations in component behavior
• Full-featured arpeggiator
• Polyphonic step sequencer with up to 64 steps
• One dedicated reverb effect with damping, pre-delay, decay and tone
• One multi-effect with stereo delay, BBD delay, tape delay, chorus, flanger, Oberheim phase shifter and ring modulator emulations, vintage rotating speaker, distortion, high-pass filter and Lo-Fi

Hardware

• 256 factory programs in classic and modern styles, with storage space for
• 256 more custom user programs
• Direct program access, including single-button access to the current set of 16 programs
• The premium 3.5 octave FATAR velocity- and touch-sensitive keyboard allows unparalleled expression and responsiveness
• Velocity sensitivity adds expressiveness to volume and filter
• Channel Aftertouch adds real-time performance-based modulation
• Modulation wheel and spring-loaded pitch wheel with selectable range per program (1 to 12 semitones up and down)
• Hold switch latches held notes on
• Manual switch: when on, the front panel is live; what you see is what you hear
• Transpose controls for +/- 2 octaves range
• Integral, fanless, heatsink-free power supply
• High-resolution OLED display enables patch management and easy access to advanced features
• Weight: 17 lbs. Dimensions: 25” L x 12.75” W x 4.4” H

Ins & Outs

• Right, Left and Headphone outputs
• Footswitch sustain and expression pedal inputs
• 5-pin DIN MIDI In, Out, Thru
• USB MIDI
